High Precision Temperature Control + Inverter Driven
High Pressure Pump + High Ambient Temp Compatibility
Cooling Capacity (50/60Hz)
- 1.3/1.5kW(RKS401/402J-MV)
- 1.8/2.0kW(RKS602J-MV)
- 2.2/2.5kW(RKS752/753J-MV)
- 4.9/5.3kW(RKS1502/1503J-MV)
Operable Ambient Temperature : 5 – 45 ℃
Working Liquid Temperature : 5 – 40 ℃
Temperature Control Accuracy : ±0.1℃
- The electronic expansion valve control achieves ±0.1 ℃ high precision temperature control that translates to increased equipment production accuracy and quality.
- Our standard built-in high-pressure pump is inverter driven, thus achieving the same performance specifications even in regions that have different power frequencies.
- Wide Operable Ambient Temperature Range of 5 – 45 ℃. Working Liquid Temperature Range of 5 – 40 ℃ Supports Many Working Environments.
- CE and UL Targeted 4-Model Lineup
Three Single-Phase 200 to 230 V Power Model: RKS402J-MV, RKS602J-MV※, RKS752J-MV, and RKS1502J-MV.
The 4 models endling in -00000, -01000, and -11000 are CE and UL standards compliant. Models with other model numbers are available as with CE compliance via special order.- UL in progress for RKS602J-MV.
